• Laundry machines - Ironing machines - Dryers

Commercial tumble dryers


Our commercial tumble dryers are designed to handle problem-free and fast your laundry. It is also important for KAAN to handle the laundry gently so that it can be used for many years without any expensive replacement. The solid quality of our machines ensures a long-lasting life and very low maintenance.

Depending on your needs, the commercial dryers are available with a capacity of 5 up to 75 kg.

In order to save as much space as possible, the different devices can be stacked on top of each other. In addition, our devices are equipped with a capacitor. Depending on the model, a radial or an axial air guide allows a good loosening as well as a perfect drying in a very short time. So our tumble dryers provide you with a reliable service.

Functionality

For electrically heated dryers with up to 16 kg, a condenser attachment is installed directly on the machine.
This re-uses the exhaust air in a tried and tested way: the air is condensed into the water and, if desired, passed on for the next use in the washing machine.

A condenser attachment for the dryer offers two significant advantages:

1. No bulky suction chimney:

Conventional dryers can only be installed in those areas which allow for a chimney installation. This limits the possibilities for positioning and is a significant problem for the layout of a laundry. On the other hand, the condenser guarantees maximum flexibility in the choice of the location.

2. No need of a specifically drilled chimney hole:

A hole in the wall often causes difficulties. Use our system and you can do without it.

Detailed view | Characteristics of our commercial dryers

DAM7/7C SDH10 DX11 DX13 DX16 DX25 DX35 DX55 DX77
Capacity kg 7 10 11,5 13,5 16 25 34 55 77
Drum volume l 112 198 271 271 347 528 634 1025 1408
Drum diameter mm 571 673 673 762 939 939 1118 1289
Electrical heating kW 2,5/3/1,3 5,2 12 21 24 30 30 60 73
Gas kW - 7,3 18,8 21,4 26,4 38,1 48,3 79 116
Vapour bar - - 6,9 6,9 6,9 6,9 6,9 6,9 6,9
Vapour kW - - 39,6 39,5 48,6 52 61,6 119 190
Weight kg 47/39/52 68 137 150 164 247 279 624 760
depth mm 585 711 1038 1191 1191 1226 1379 1725 1749
length mm 595 683 711 711 800 981 981 1178 1349
height mm 850 1092 1622 1622 1622 1946 1946 2177 2388
